Routing Engine 0 BUILTIN BUILTIN QFX Routing Engine
FPC 0 REV 17 750-036931 P5331-C QFX5100-24Q-2P
CPU BUILTIN BUILTIN FPC CPU
PIC 0 BUILTIN BUILTIN 24x 40G-QSFP
Power Supply 0 Rev 04 740-032091 VB02420 QFX3500-48S4Q
Power Supply 1
Fan Tray 1 QFX5100 Fan Tray 1, Bac
k to Front Airflow - AFI
Fan Tray 2 QFX5100 Fan Tray 2, Bac
k to Front Airflow - AFI
Fan Tray 3 QFX5100 Fan Tray 3, Bac
k to Front Airflow - AFI
Fan Tray 4 QFX5100 Fan Tray 4, Bac
k to Front Airflow - AFI
Fan Tray 5 QFX5100 Fan Tray 5, Bac
k to Front Airflow - AFI
NOTE: You must remove the fan module to read the fan serial number from the serial number
ID label. The fan module serial number cannot be viewed through the CLI. Fan Tray 2 refers to
the third module from the left, counting from 0.
Locating the Chassis Serial Number ID Label on a QFX5100 Switch
The location for the chassis serial number ID label is product SKU-dependent. On the QFX5100-96S,
QFX5100-48S, QFX5100-48SH, QFX5100-48T, and QFX5100-48TH product SKUs, the serial number
ID label is located on the left side of the port panel. On legacy switches, or switches with an LCD, the port
panel is referred to as the front panel. See Figure 221 on page 592 through Figure 223 on page 592 for
examples of where to find the serial number ID. On the QFX5100-24Q, the serial number ID label is located
next to the left expansion port on the port panel. See Figure 224 on page 593.
591
