Page #156 background imageLoading...
Page #156 background image
Management Port Connector Pinouts for the QFX Series
The 1000BASE-T RJ-45 management ports use an RJ-45 connector to connect either to the control plane
and management network in a QFabric system, or to a management device for out-of-band management.
Table 33 on page 132 provides the pinout information of the RJ-45 management port connector. An RJ-45
cable is supplied with the QFX Series device.
NOTE: The RJ-45 pinout information in Table 33 on page 132 also applies to the QFX5100-48T
device 10GBASE-T access ports.
Table 33: RJ-45 Management Port Connector Pinouts for the QFX Series
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1–2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4–8
RELATED DOCUMENTATION
Management Port LEDs on a QFX3100 Director Device
Management Port LEDs in the QFX3600 and QFX3600-I Device | 520
Management Port LEDs on a QFX3500 Device | 529
Management Port LEDs on a QFX5100 Device | 508
QFX10002 Management Port LEDs
QFX10000 Routing and Control Board LEDs
132
