If you are returning a switch or component to Juniper Networks for repair or replacement, you must locate
the serial number of the switch or component. You must provide the serial number to the Juniper Networks
Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization
(RMA). See “Contact Customer Support to Obtain Return Material Authorization” on page 621.
If the switch is operational and you can access the command-line interface (CLI), you can list serial numbers
for the switch and for some components with a CLI command. If you do not have access to the CLI or if
the serial number for the component does not appear in the command output, you can locate the serial
number ID label on the switch or component.
NOTE: If you want to find the serial number ID label on a component, you need to remove the
component from the switch chassis, for which you must have the required parts and tools
available.
Listing the Chassis and Component Details Using the CLI
To list the QFX5110 switch and components and their serial numbers, use the show chassis hardware CLI
operational mode command.
user@device> show chassis hardware
user@device> show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis WS3115130011 QFX5110-48S-4Q
Pseudo CB 0
Routing Engine 0 BUILTIN BUILTIN RE-QFX5110-48S-4Q
FPC 0 REV 03 650-061152 WS3115290015
CPU BUILTIN BUILTIN FPC CPU
PIC 0 BUILTIN BUILTIN 48x10G-4x100G
Xcvr 34 REV 01 740-030658 AD1148A0AXP SFP+-10G-USR
Xcvr 35 REV 01 740-030658 AD1148A0APE SFP+-10G-USR
Xcvr 48 REV01 740-061001 LEO150600KQ QSFP28-100G-CU3M
Xcvr 49 REV01 740-061001 LEO150600KQ QSFP28-100G-CU3M
Xcvr 50 REV 01 740-038624 MOC13346240015 QSFP+-40G-CU3M
Power Supply 0 REV 03 740-041741 1GA24141198 JPSU-650W-AC-AFO
Power Supply 1 REV 03 740-041741 1GA24141173 JPSU-650W-AC-AFO
Fan Tray 0 fan-ctrl-2 0, Front to
Back Airflow - AFO
Fan Tray 1 fan-ctrl-2 1, Front to
587
