Front Panel of a QFX3500 Device
The front panel of the QFX3500 device consists of the following components:
•
Management board
•
Chassis serial number label and ESD point
NOTE: The chassis serial number ID label is located on a sliding panel to the right of the fan
tray on a QFX3500 device (see Figure 29 on page 56). To use the sliding panel as an ESD point,
pull the sliding panel partway out of the chassis, and connect a clip-style or tape-style ESD
grounding strap to the panel.
•
Fan trays
•
Power supplies
Figure 28 on page 56 and Figure 29 on page 56 show the front of a QFX3500 device.
Figure 28: QFX3500 Device Front Panel
1
1
0
0
QFX3500-48S4Q
CO
C
O
N
C1
OK/
g050012
Management
board
Fan tray 0 Fan tray 1
AC power
supply 0
AC power
supply 1
Figure 29: QFX3500 Device Front
FX3500-48S4Q
CO
C1
Management
board
Fan
tray
Fan
tray
Power
supply
Power
supply
Mounting
bracket
Mounting
bracket
g050000
ESD point/
serial number
ID label
RELATED DOCUMENTATION
Field-Replaceable Units in a QFX3500 Device
Rear Panel of a QFX3500 Device
56

Juniper QFX5110 Series Specifications

General

Rack Units	1U
Operating System	Junos OS
Form Factor	Fixed
Management	CLI, SNMP, NETCONF
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100-240 VAC
Power Supply	Redundant, hot-swappable
