Table 36: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts (continued)
PinPin
49
310
211
112
Cable Specifications for Console and Management Connections for the
QFX Series
Table 37 on page 146 lists the specifications for the cables that connect the QFX Series switch to a
management device.
NOTE: The QFX Series can be configured with SFP management ports that support 1000BASE-SX
transceivers. See the Hardware Compatibility Tool for more on the fiber-optic cables required
for use with these transceivers.
Table 37: Cable Specifications for Console and Management Connections for the QFX Series
Device
Receptacle
Maximum
LengthCable SuppliedCable Specification
Port on QFX
Series Device
RJ-457 feet
(2.13 meters)
One 7-foot (2.13-meter) long
RJ-45 patch cable and RJ-45
to DB-9 adapter
RS-232 (EIA-232) serial
cable
Console port
RJ-45328 feet
(100 meters)
One 7-foot (2.13-meter) long
RJ-45 patch cable
Category 5 cable or
equivalent suitable for
1000BASE-T operation
Management port
