Rack-Mounting and Cabinet-Mounting Warnings | 224
Mounting an EX4300 Switch in a Recessed Position in a Rack or Cabinet
You can mount an EX4300 switch in a recessed position on two posts of either a two-post rack or a
four-post rack such that the switch is recessed inside the rack from the rack front by 2 inches. To mount
the switch in a recessed position, use the front-mounting brackets provided in the separately orderable
four-post rack-mount kit.
Reasons to mount the switch in a recessed position include:
•
You are mounting the switch in a cabinet and the cabinet doors do not close completely unless the switch
is recessed.
•
The switch you are mounting has an uplink module with transceivers installed in it—the transceivers in
the uplink module ports protrude from the front of the switch.
To mount the switch in a recessed position, on two-posts or on four-posts, follow the instructions in
“Mounting an EX4300 Switch on Two Posts of a Rack or Cabinet” on page 356 or “Mounting an EX4300
Switch on Four Posts of a Rack or Cabinet” on page 359.
RELATED DOCUMENTATION
Connect Earth Ground to an EX Series Switch
Rack-Mounting and Cabinet-Mounting Warnings | 224
Mounting an EX4300 Switch on a Wall
You can mount an EX4300 switch on a wall by using the separately orderable wall-mount kit.
Before mounting the switch on a wall:
•
Verify that the site meets the requirements described in “Site Preparation Checklist for EX4300 Switches”
on page 97.
•
Read “General Safety Guidelines and Warnings” on page 203, with particular attention to Chassis and
Component Lifting Guidelines.
•
Remove the switch from the shipping carton (see “Unpacking an EX4300 Switch” on page 354).
Ensure that you have the following parts and tools available:
363
