CHAPTER 33
Replacing QFX3500 Components
IN THIS CHAPTER
Installing and Removing QFX3500 Device Hardware Components | 452
Installing a Power Supply in a QFX3500 Device | 453
Removing a Power Supply from a QFX3500 Device | 455
Installing a Fan Tray in a QFX3500 Device | 457
Removing a Fan Tray from a QFX3500 Device | 459
Installing a Management Board in a QFX3500 Device | 460
Removing a Management Board from a QFX3500 Device | 462
Installing and Removing QFX3500 Device Hardware Components
The QFX3500 device chassis is a rigid sheet-metal structure that houses the hardware components. The
field-replaceable units (FRUs) in QFX3500 devices are:
•
Power supply
•
Fan tray
•
Management board
•
SFP transceiver
•
SFP+ transceiver
•
QSFP+ transceiver
All of the QFX3500 device FRUs except the management board are hot-insertable and hot-removable:
you can remove and replace them without powering off the device or disrupting device functions. You
must power off the QFX3500 device before replacing the management board.
CAUTION: Replace a failed power supply with a blank panel or new power supply
within 1 minute of removal to prevent chassis overheating. Replace a failed fan tray
with a new fan tray within 1 minute of removal to prevent chassis overheating.
452
