Management Panel of a QFX5100 Device

show chassis alarms

request chassis beacon

Management Port LEDs on a QFX5100 Device

The management ports (labeled C0 for 10/100/1000 Base-T and C1 for 10/100/1000 Base-T and SFP

1000 Base-X connections) on a QFX5100 switch have two LEDs that indicate link status and link activity

(see Figure 187 on page 509). The left LED indicates status; the right LED indicates link/activity.
