If you are using the QFX3500 device as a Node device in a QFX3000-G QFabric system, see
QFX3000-G QFabric System Installation Overview for information about the steps to install and configure
your QFX3000-G QFabric system.
•
If you are using the QFX3500 device as a Node device in a QFX3000-M QFabric system, see
QFX3000-M QFabric System Installation Overview for information about the steps to install and
configure your QFX3000-M QFabric system.
RELATED DOCUMENTATION
Rack Requirements for a QFX3500 Device | 114
Cabinet Requirements for a QFX3500 Device | 119
Clearance Requirements for Airflow and Hardware Maintenance for a QFX3500 Device | 125
Unpacking a QFX3500 Device
The QFX3500 device chassis is a rigid sheet-metal structure that houses the hardware components. A
QFX3500 device is shipped in a cardboard carton, secured with foam packing material. The carton also
contains an accessory box and quick start instructions.
CAUTION: QFX3500 devices are maximally protected inside the shipping carton. Do
not unpack the device until you are ready to begin installation.
To unpack a QFX3500 device:
1. Move the shipping carton to a staging area as close to the installation site as possible, but where you
have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory box and verify the contents against the inventory included in the box.
Table 71 on page 328 lists the inventory of components supplied with a QFX3500 device.
5. Pull out the packing material holding the device in place.
327
