Juniper QFX5110 Series - QFX5110 Fan Module LED

Table 77: QFX5110-32Q Access Port and Uplink LED Locations
g050236
Bi-colored LEDs
Link and
Activity
Status
QSFP28 and
QSFP+
QFX5110-32Q
RELATED DOCUMENTATION
QFX5110 Management Panel
Install a Transceiver
Connect a Fiber-Optic Cable
QFX5110 Fan Module LED
Figure 183 on page 500 shows the location of the LED next to the fan module.
Figure 183: Fan Module LED in a QFX5110 Switch
g050487
CO
CON
ALM
SYS
MST
ID
RESET
CO
1
1—Fan LED
Table 78 on page 501 describes the function of the fan tray LED.
500
