CHAPTER 15
Planning EX4300 Power Requirements
IN THIS CHAPTER
AC Power Supply in EX4300 Switches | 170
AC Power Cord Specifications for an EX4300 Switch | 180
DC Power Supply in EX4300 Switches | 184
AC Power Supply in EX4300 Switches
IN THIS SECTION
Characteristics of an AC Power Supply | 171
AC Power Supply Airflow | 173
N+0 Redundancy Configuration of AC Power Supplies | 174
N+N Redundancy Configuration of AC Power Supplies | 177
The AC power supply in EX4300 switches is a hot-insertable and hot-removable field-replaceable unit
(FRU): You can install it without powering off the switch or disrupting the switching function.
All the EX4300 switches that are powered by AC power supplies, except EX4300-24T-S, EX4300-24P-S,
EX4300-32F-S, EX4300-48T-S, EX4300-48P-S, and EX4300-48MP-S switches are shipped with one AC
power supply installed in the rear panel of the switches. EX4300-24T-S, EX4300-24P-S, EX4300-32F-S,
EX4300-48T-S, EX4300-48P-S, and EX4300-48MP-S switches are not shipped with power supplies; you
must order the power supplies separately.
NOTE: EX4300 switches except EX4300-48MP and EX4300-48MP-S switches support 350 W,
715 W, and 1100 W AC power supplies. EX4300-48MP and EX4300-48MP-S switches support
715 W, 1100 W, and 1400 W AC power supplies.
170
