Juniper QFX5110 Series User Manual

CAUTION: Verify that the direction of the arrow on the power supply handle
matches the direction of airflow in the chassis. Ensure that each power supply you
install in the chassis has the same airflow direction. If you install power supplies
with two different airflow directions, Junos OS raises an alarm, and the status (ALM)
LED blinks amber.
3. Using both hands, lift the power supply and place it over the EMI gasket (if present) in the power supply
slot and slide the power supply into place.
Figure 138: Installing a Power Supply in a QFX5110-32Q with EMI Gasket
NOTE: The EMI gasket is not present in QFX5110-48S switch.
4. Ensure the power supply is fully seated and the locking lever is in place.
Figure 139: Installing a Power Supply in a QFX5110-48S
QFX5100-48S
RUNNING JUN OS
426

Juniper QFX5110 Series Specifications

General

Rack Units	1U
Operating System	Junos OS
Form Factor	Fixed
Management	CLI, SNMP, NETCONF
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100-240 VAC
Power Supply	Redundant, hot-swappable
