Table 96: Chassis Status LEDs on a QFX3500 Device
DescriptionStateColorName
The device is powered on.On steadilyGreenPower
A temperature or voltage error has been detected, and the device has shut
down. Power off the QFX3500 device by setting the AC power source outlet
to the OFF (O) position, or unplugging the AC power cords. Correct any site
temperature issues, and allow the device to cool down. Power on the
QFX3500 device and monitor the power supply and fan LEDs to help
determine where the error is occurring. If the amber Power LED begins
blinking again, power off the QFX3500 device and contact customer support.
See “Contacting Customer Support to Obtain a Return Materials
Authorization for a QFX Series Device or Component” on page 619.
BlinkingAmber
Junos OS has been loaded on the device.On steadilyGreenStatus
The beacon feature has been enabled on the device using the request chassis
beacon command.
Intermittent
blinking
A software error has occurred. Power off the QFX3500 device by setting
the AC power source outlet to the OFF (O) position, or unplugging the AC
power cords. Power on the QFX3500 device and monitor the management
board LEDs to ensure that Junos OS boots properly.
BlinkingAmber
The fan modules on the management board are operating normally.On steadilyGreenFan
An error has been detected in the fan modules installed on the management
board. Replace the management board as soon as possible. You must power
off the QFX3500 device before replacing the management board. See
“Removing a Management Board from a QFX3500 Device” on page 462.
BlinkingAmber
RELATED DOCUMENTATION
Front Panel of a QFX3500 Device | 56
Chassis Alarm Messages on a QFX3500 Device | 632
528
