Table 106: Health Status (continued)
DescriptionField
Indicates the memory used in the primary Routing Engine. Click the backup Routing Engine
to view the memory used in the backup Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.Fan status
EX8208 Switches
Indicates the memory used in the external Routing Engine. In an EX8200 Virtual Chassis,
the memory utilization value of the XRE200 External Routing Engine in the primary role is
displayed. Click the XRE200 External Routing Engine in the backup role to view the memory
used in the backup external Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
EX8216 Switches
Indicates the memory used in the external Routing Engine. In an EX8200 Virtual Chassis,
the memory utilization value of the XRE200 External Routing Engine in the primary role is
displayed. Click the XRE200 External Routing Engine in the backup role to view the memory
used in the backup external Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
XRE200 External Routing Engines
Indicates the memory used in the external Routing Engine. In an EX8200 Virtual Chassis,
the memory utilization value of the XRE200 External Routing Engine in the primary role is
displayed. Click the backup XRE200 External Routing Engine to view the memory used in
backup external Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
546
