Table 109: Chassis Viewer for EX2200-C Switches (continued)
DescriptionField
The console port is used to connect the switch to a management console or to a console
server. (You might do this for initial switch configuration.)
Console port
Indicates the USB port for the switch.
NOTE: We recommend that you use USB flash drives purchased from Juniper Networks
for your EX Series switch.
USB port
Rear View
Mouse over the power outlet icon to display name, status, and description information.Power supply
Table 110: Chassis Viewer for EX3200, EX3300, and EX4200 Switches
DescriptionField
Front View
In the image, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is nonoperational.
•
Gray—Interface is down and nonoperational.
Mouse over the interface (port) to view more information.
For a Virtual Chassis configuration, select the switch to view the interface status.
If an SFP+ uplink module is installed in the switch, mouse over the port icon to display
whether the module is configured to operate in 1-gigabit mode or in 10-gigabit mode. If
the module is configured to operate in 1-gigabit mode, the tool tip information is displayed
for all 4 ports. If the module is configured to operate in 10-gigabit mode, the tool tip
information is displayed only for 2 ports.
On an EX3300 switch with the 4x GE/XE SFP+ module, mouse over the port icon to display
whether the module is configured to operate in 1-gigabit mode or 10-gigabit mode.
For SFP, SFP+, and XFP ports, the interfaces appear dimmed if no transceiver is inserted.
The chassis viewer displays Transceiver not plugged-in when you mouse over the port
icon.
Interface status
LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current
character display.
LCD panel
550
