Interactive SourceMeter® Instrument Reference Manual Appendix D:
Model 2450 in a Model 2400 application
2450-901-01 Rev. B/September 2013 D-17
Model 2400 command
:SOURce[1]:CURRent:CENTer
:SOURce[1]:CURRent:CENTer?
:SOURce[1]:VOLTage:CENTer
:SOURce[1]:VOLTage:CENTer?
Model 2450 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-81)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-83)
:SOURce[1]:SWEep:<function>:LIST (on page 6-85)
:SOURce[1]:SWEep:<function>:LOG (on page 6-87)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-51) for information.
Model 2400 command
:SOURce[1]:CURRent[:LEVel][:IMMediate][:AMPLitude]
:SOURce[1]:CURRent[:LEVel][:IMMediate][:AMPLitude]?
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Model 2450 command
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude] (on page 6-70), where
<function> is CURRent or VOLTage.
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Notes
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered[:AMPLitude]
:SOURce[1]:CURRent[:LEVel]:TRIGgered[:AMPLitude]?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered[:AMPLitude]
:SOURce[1]:VOLTage[:LEVel]:TRIGgered[:AMPLitude]?
Model 2450 command
Notes
Use the Trigger model (on page 3-95).
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor?
Model 2450 command
Notes
Use the Trigger model (on page 3-95).
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor:STATe
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor:STATe?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor:STATe
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor:STATe?
Model 2450 command
Not available
Notes
Use the Trigger model (on page 3-95).
Model 2400 command
:SOURce[1]:CURRent:MODE?
:SOURce[1]:VOLTage:MODE
Model 2450 command
:SOURce[1]:FUNCtion[:MODE] (on page 6-72)
:SOURce[1]:FUNCtion[:MODE]?
Notes
