Kikusui TOS9301 - Operation after a Test Starts

102 User’s Manual TOS93 Series
Earth Continuity Test | Starting a Test
 Contact check in progress display
When Contact Check (p.98) is set to on, “CHECK” appears during the contact check.
Operation after a test starts
Shown below are examples of operation after a test starts.
PASS
Output off
Test Current
TESTRISE
READY
Rise Time
Fall Time
Press START.Press START.
FALL
DANGER LED litDANGER LED lit
Test
Status
Lower judgment
begins.
Lower judgment
begins.
PASS judgmentPASS judgment
Ŷ
Example of a PASS judgment (applies to AC and DC tests)
Test Time: ON
Rise Time: ON
Fall Time: ON
Test Time
Upper judgment
begins.
Upper judgment
begins.
Ŷ
Example of a FAIL judgment (applies to AC and DC tests)
Test Time: ON
Rise Time: ON
Fall Time: ON
Upper-FAIL
Output off
Test Current
TESTRISE
READY
Rise Time
DANGER LED litDANGER LED lit
Test
Status
Upper-FAIL detectionUpper-FAIL detection
Test Time
Press START.Press START.
Lower judgment
begins.
Lower judgment
begins.
Upper judgment
begins.
Upper judgment
begins.
