Auto Test | Auto Test Overview
Main functions
The following types of programs are available. Programs are saved in the product’s memory.
Settable items
There are functions that can be set for each step, and those that can be set for each program.
Items that cannot be set
You cannot set the following functions.
• Set TestTime to OFF
• Auto Measure when setting the offset
• Set Judgment Lower to OFF when Judge Type is set to Ω (Resistance) in an IR test
• Set Judgment Upper to OFF when Judge Type is set to A
(C
urrent) in an IR test
• Set Judgment Upper to OFF when Judge Type is set to Ω (Resistance) in an EC test
• Set Judgment Upper to OFF when Judge Type is set to V
(V
oltage) in an EC test
• Set Judgment Upper to OFF in a LC test
• LineOUT in a LC test
Supported
tests
Type Maximum
number of
programs
Maximum
number of
steps
1
1 Per program
Executed
under external
control
2
2 See “Recalling from memory” (p.241) and “Starting and Stopping Tests” (p.242).
Changing
the program
name
Notes
Except LC
tests
Program 100 100 –

–
Program
memory
25 100

– Can be registered in
memory numbers 51 to 75
LC tests
only
3
3 TOS9303LC only
Program 100 100 –

–
Program
memory
24 100

– Can be registered in
memory numbers 76 to 99
Scope Setting Description
By step Test conditions of each test You can set test conditions that are similar to those that
are used when running tests individually, with a few
exceptions.
For each program Step start operation Set the conditions for starting the test.
Step interval Set the step interval time.
Fail judgment operation Set whether to stop the auto test or run all steps when a
fail
judgment occurs.
EUT power supply Set whether to cut off the power supply to the EUT or
cont
inue the power supply to the EUT after the
completion of each step.
