TOS93 Series User’s Manual 141
Touch Current Test | Setting Test Conditions
Upper limit
Set the reference current for upper limit judgment. If current greater than or equal to Upper is measured,
upper limit judgment (Upper-FAIL) results. To disable upper limit judgment, set Upper to off.
1
On the Home menu screen, press Judgment > Upper.
2
Press Upper to switch between on and off.
Upper switches between on and off each time you press the key.
3
If you select on, use the numeric keypad or the rotary knob to enter the current.
For the setting range, see the measurement range (p.301) in the specifications.
This completes the setting.
