Touch Current Test | Setting Test Conditions
Measurement range
Set the measurement range.
 Measurement range when Fix is selected
Value Description
Auto Switches the range automatically according to the measured values.
Fix The measurement range is fixed Range 1 to 4 according to the Network, Upper, and
Measure Mode settings. See “Measurement range when Fix is selected” below.
Network Upper
Range setting
1
1 For the measurement range of each range setting, see the specifications (p.301).
Measure Mode: Peak Measure Mode: RMS (AC+DC),
RMS (AC), DC
A, B, C, H 0.1 µA to 85 µA 0.1 µA to 60 µA Range 1
86 µA to 850 µA 61 µA to 600 µA Range 2
851 µA to 8.50 mA 601 µA to 6.00 mA Range 3
8.51 mA to 85.0 mA 6.01 mA to 60.0 mA Range 4
D, E, I 0.1 µA to 42.4 µA 0.1 µA to 30 µA Range 1
42.5 µA to 424 µA 31 µA to 300 µA Range 2
425 µA to 4.50 mA 301 µA to 3.00 mA Range 3
45.1 mA to 45.0 mA 3.01 mA to 30.0 mA Range 4
F 0.1 µA to 28.2 µA 0.1 µA to 20 µA Range 1
28.3 µA to 282 µA 20.1 µA to 200 µA Range 2
283 µA to 3.00 mA 201 µA to 2.00 mA Range 3
3.01 mA to 30.0 mA 2.01 mA to 20.0 mA
Range 4
G 0.1 µA to 21.2 µA 0.1 µA to 15 µA Range 1
21.3 µA to 212 µA 15.1 µA to 150 µA Range 2
213 µA to 2.12 mA 151 µA to 1.50 mA Range 3
2.13 mA to 22.5 mA 1.51 mA to 15.0 mA Range 4
