322 User’s Manual TOS93 Series
Appendix
Timing Charts
Typical examples of timing charts are provided below.
Contact check operation
Setting conditions
Model: TOS9301 (connect a high voltage scanner)
Contact Check: ON
CH1 to CH4 of the scanner: Low
Rise Time: ON
Test Time: ON
Start the test with the SIGN
AL I/O
No. Description No. Description
(1) 5 ms min. (5) Varies depending on the EUT
(2)
Approx. 180 ms
1
1 TYP (typical value)
(6)
Approx. 50 ms
*1
(3) Rise Time (7)
Approx. 30 ms
*1
(4) Test Time
START
H.V ON
TEST
1CH High
1CH Low
2CH High
2CH Low
3CH High
3CH Low
4CH High
4CH Low
(2)
(3) (4) (5)
(6) (7)
(7)
(7)
To Next Page
