334 User’s Manual TOS93 Series
Appendix | Options
Brackets
Brackets are rack mounting options. There are two types of brackets: EIA standard and JIS standard.
• KRB3-TOS: EIA inch rack Standard
• KRB15
0-TOS: JIS millimeter rack standard
Removing the feet
We recommend that you keep all pieces that you remove from the product. You will need these pieces if
you remove the product from the rack.
1
Pry off the pins holding the legs (four locations) with a flat-blade screwdriver.
2
Remove the legs (four locations).
This completes the removal.
Attaching the rack adapter or bracket.
For information on rack mounting, see the operation manual of the relevant bracket.
Pry the pins off with a
flat-blade screwdriver.
Pin
When mounting the product on a rack, be sure to use support angles (auxiliary brackets) to
safely support the product.
