TOS93 Series User’s Manual 189
Patient Leakage Current Test | Setting Test Conditions
Measurement mode (Measure Mode)
Set the current measurement mode. An icon appears during testing according to the setting.
1
On the Home menu screen, press Measure repeatedly until Measure is selected.
Each time you press the key, the setting changes between Measure and Scale.
2
Press Measure Mode and then turn the rotary knob to change the value.
This completes the setting.
Value Description
Icon
Peak Measures the waveform peak value.
RMS (AC+DC) Measures the DC component and AC component with true rms values.
RMS (AC) Measures only the AC component with true rms values.
DC Measures only the DC component.
To Next Page
