External Control | SIGNAL I/O Connector
Connecting to the SIGNAL I/O connector
To connect the signal cable to the SIGNAL I/O connector, create a D-sub37 pin plug by referring to the
following information.
SIGNAL I/O connector
specifications
D-sub 37-pin female connector (socket), #4-40 UNC inch screws
Compatible plug D-sub 37-pin male (with #4-40 UNC fixing screws)
To prevent malfunction caused by noise, use a shielded plug.
Required cable Single wire: 0.32 mm (AWG28) to 0.65 mm (AWG22) in diameter
Twisted wire: 0.32 mm
2
(AWG22) to 0.08 mm
2
(AWG28)
To prevent malfunction caused by noise, use a cable no longer than 2.5 m.
Required tools Wire stripper for the above cable
