Kikusui TOS9301 - Interface specifications

306 User’s Manual TOS93 Series
Specifications | Interface
Interface
Measurement
terminal
Rated voltage Between the A
and B terminals
250 V
Between the
terminals and
chassis
250 V
Rated current: 100 mA
Measurement category CAT-II
Valid terminal display Terminals valid for measurement are indicated on the display.
110% terminal A terminal for supplying the voltage applied to the AC LINE IN inlet.
Power supply
for the EUT
Nominal voltage range 100 V to 240 V, 50 Hz/60 Hz
Input voltage range (allowable
voltage range)
85 Vac to 250 Vac
Rated output capacity 1 500 VA
Maximum operating current 15 A (Overcurrent protection is activated at approximately 15.7 A.)
Inrush current 70 Apeak max. (within 20 ms)
1 If voltage is measured with the A and B terminals open, measurements will be easily affected by induced voltage.
Item Specifications
Item Specifications
REMOTE MINI DIN 9-pin connector. Connect the following option to remotely
control the starting and stopping of tests.
• Remote control box RC01-TOS, RC02-TOS
• High voltage test probe HP01A-TOS, HP02A-TOS
(when the test voltage is 4 kVac 5 kVdc or less)
SIGNAL I/O D-sub 37-pin connector. For the pin arrangement, see p.235 .
Function Enable/disable interlock, recall setup memories, recall auto test
programs, start/stop testing, monitor the test and voltage
generation status, monitor the test status, monitor judgment results,
monitor the step execution status of auto tests, monitor the
activation status of protection functions
Input specifications The input signals are all low-active control. The input terminal is
pulled up to +12 V by a resistor. Leaving the input terminal open is
equivalent to applying a high level signal.
High-level input voltage 11 V to 15 V
Low-level input voltage 0 V to 4 V
Low-level input current -5 mA max.
Input time width 5 ms min.
Output
specifications
Output method Open collector output (4.5 Vdc to 30 Vdc)
Output withstanding voltage 30 Vdc
Output saturation voltage Approx. 1.1 V (25 °C)
Maximum output current 400 mA(TOTAL)
STATUS OUT Output terminal of an option product.
Positive terminal (red) Outputs +24 V. Use Status Out of CONFIG settings to set the output
conditions.
Negative terminal (black) +24 V circuit common.
