TOS93 Series User’s Manual 307
Specifications | Interface
SCANNER MINI DIN 8-pin connector. Terminal for the optional TOS9320 high
voltage scanner. The maximum number of connections is 4 devices
(16 channels).
USB (host) Standard type A socket, FAT32, 32 GB or less
Complies with the USB 2.0 specifications; data rate: 480 Mbps
(high speed)
Remote control All functions except turning on and off the power, key lock, and auto
test can be remotely controlled.
RS232C Hardware D-sub 9-pin connector (EIA-232D compliant)
Baudrate: 9 600, 19 200, 38 400, 57 600, 115 200 bps
Data length: 8 bits; stop bits: 1 bit; parity bit: none, flow control:
none/CTS-RTS
Message terminator LF during reception, LF during transmission.
USB (device) Hardware Standard Type B connector
Complies with the USB 2.0 specifications; data rate: 480 Mbps
(high speed)
Message terminator LF or EOM during reception, LF + EOM during transmission.
Device class Complies with the USBTMC-USB488 device class specifications.
LAN Hardware IEEE 802,3 100Base-TX/10Base-T Ethernet
Auto-MDIX compliant.
IPv4, RJ-45 connector.
Compliant standards LXI 1.5 Core Specification 2011
Communication protocol VXI-11, HiSLIP, SCPI-RAW, SCPI-Telnet
Message terminator VXI-11, HiSLIP: LF or END during reception, LF + END during
transmission.
SCPI-RAW: LF during reception, LF during transmission.
Display 7-inch LCD
Item Specifications
