84 User’s Manual TOS93 Series
Withstanding Voltage and Insulation Resistance Tests | Starting a Test
Operation after a test starts
Shown below are examples of operation after a test starts.
Output off
Test Voltage
Start Voltage
TESTRISE
READY
Rise Time
Fall Time
Press START.Press START.
FALL
DANGER LED litDANGER LED lit
Test
Status
Judgment begins.Judgment begins.
PASS judgmentPASS judgment
Ŷ
Example of an ACW test (PASS judgment)
0.1 s
Start Voltage: ON
Test Time: ON
Rise Time: ON
Fall Time: ON
Test Time
PASS
Discharge
Time
Upper-FAIL
Output off
Test Voltage
Start Voltage
Judge Delay
TESTRISE
READY
Rise Time
Upper judgment
begins.
Upper judgment
begins.
Press START.Press START.
DANGER LED litDANGER LED lit
Test
Status
Lower judgment begins.Lower judgment begins. Upper-FAIL detectionUpper-FAIL detection
Ŷ
Example of a DCW test (FAIL judgment)
0.1 s
Start Voltage: ON
Lower: ON
Delay Auto: OFF
Test Time: ON
Rise Time: ON
Fall Time: ON
Discharge Time: 10 s
Test Time
30 V
Discharge
Time
Output off
Test Voltage
TESTRISE
READY
Rise Time
Press START.Press START.
DANGER LED litDANGER LED lit
Test
Status
Judgment begins.Judgment begins. PASS judgmentPASS judgment
Ŷ
Example of an IR test (PASS judgment)
Start Voltage: OFF
Upper: ON
Lower: ON
Delay Auto: ON
Test Time: ON
Rise Time: ON
Discharge Time: 0 s
Test Time
PASS
30 V
