310 User’s Manual TOS93 Series
Specifications | General specifications
General specifications
Item Specifications
Backup battery life 3 years (at 25 °C)
Environment Installation location Indoors, 2 000 m or less
Spec guaranteed
range
Temperature 5 °C to 35 °C (41 °F to 95 °F) (18°C to 28°C for partial discharge
tests)
Humidity 20 %rh to 80 %rh (20%rh to 70%rh for partial discharge tests) (no
condensation)
Operating range Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 20 %rh to 80 %rh (no condensation)
Storage range Temperature -20 °C to 70 °C (-4 °F to 158 °F)
Humidity 90 %rh or less (no condensation)
Power
supply
Nominal voltage range (allowable
voltage range)
100 Vac to 120 V, 200 V to 240 V (90 Vac to 132 V, 170 V to 250 V)
Power
consumption
No load
(READY state)
100 VA or less
Rated load 800 VA max.
Allowable frequency range 47 Hz to 63 Hz
Insulation resistance
(between AC LINE and chassis)
30 MΩ or more (500 Vdc)
Withstanding voltage
(between AC LINE and chassis)
1500 Vac, 1 minute, 20 mA or less
Earth continuity 25 Aac, 0.1 Ω or less
Dimensions See p.311 .
Weight
TOS9300: Approx. 17 kg (37.5 lb.), TOS9301: Approx. 18 kg (39.7 lb.),
TOS9301PD: 22
kg (48.5 lb.), TOS9302: Approx. 20 kg (44.1 lb.),
TOS9303: Approx. 21 kg (46.3 lb.), TOS9303LC: Approx. 22 kg (48.5 lb.)
Accessories See p.4 .
Electromagnetic compatibility
1
2
Complies with the requirements of the following directive and standards.
EMC Directive 2014/30/EU
EN 61326-1 (Class A
3
)
EN 55011 (Class A
*3
, Group 1
4
)
EN 61000-3-2
EN 61000-3-3
Applicable under the following conditions
The maximum length of all cabling and wiring connected to the
product must be less than 2.5 m.
Shielded cables are being used when using the SIGNAL I/O.
The high-voltage test lead TL31-TOS is in use.
Electrical discharges are applied only to the EUT.
Safety
*1
Complies with the requirements of the following directive and standards.
Low Voltage Directive 2014/35/EU
*2
EN 61010-1 (Class I
5
, Pollution Degree 2
6
)
1 Does not apply to specially ordered or modified products.
2 Only on models that have CE/UKCA marking on the panel.
3 This is a Class A instrument. This product is intended for use in an industrial environment. This product may cause
interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce
electromagnetic emissions to prevent interference to the reception of radio and television broadcasts.
4 This is a Group 1 instrument. This product does not generate and/or use intentionally radio-frequency energy, in the form of
electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purpose.
5 This is a Class I instrument. Be sure to ground this product's protective conductor terminal. The safety of this product
is guaranteed only when the product is properly grounded.
6 Pollution is addition of foreign matter (solid, liquid or gaseous) that may produce a reduction of dielectric strength or
surface resistivity. Pollution Degree 2 assumes that only non-conductive pollution will occur except for an occasional
temporary conductivity caused by condensation.
