244 User’s Manual TOS93 Series
External Control | Monitoring the Test Status
Monitoring judgment results
PASS judgment
When the judgment result is PASS, under the following conditions, SIGNAL I/O PASS (pin 25) is set to low
level:
• Until the time set by Pass
Hold (p.267) is elapsed or the judgment result is cleared.
• Until the STOP switch is pressed or a STOP signal is received if Pass Hold is set to Infinity.
• Dur
ing the step interval when PASS ju
dgment is made for a step if Step END Judgment (p.269) is
enabled in an auto test.
UPPER FAIL judgment
When the judgment result is Upper-FAIL, under the following conditions, SIGNAL I/O U FAIL (pin 26) is set
to low level:
• Until the judgment result is cleared.
• During the Interval time if a judgment result of a step is Upper-FA
IL
when Step END Judgment (p.269)
is enabled in an auto test or FAIL
Judgment (p.224) is set to Continue.
LOWER FAIL judgment
When the judgment result is Lower-FAIL, under the following conditions, SIGNAL I/O L FAIL (pin 27) is set
to low level:
• Until the judgment result is cleared.
• During the Interval time if a judgment result of a step is FA
IL
when Step END Judgment (p.269) is
enabled in an auto test or FAIL
Judgment (p.224) is set to Continue.
CONTACT FAIL judgment
When the judgment result is Contact-FAIL, both U FAIL (pin 26) and L FAIL (pin 27) is set to low level
simultaneously.
