134 User’s Manual TOS93 Series
Touch Current Test
Applicable model:
This chapter describes how to set test conditions, start tests, and view the results for touch current (TC) of
leakage current (LC) tests.
The following flowchart shows the configuration and test steps.
Setting Test Conditions
This section describes the test conditions of touch current (TC) tests and how to set the conditions.
Displaying the setup screen (Home menu)
1
On the Function menu screen (p.46), press LC >TC.
The setup screen (Home menu) for the TC test conditions appears.
Set the required conditions by referring to the description of test conditions
(p.135).
9303LC
Start a test.
Set test conditions.
Finish the test and judge.
(p.134)
(p.152)
(p.157)
To Next Page
