96 User’s Manual TOS93 Series
Earth Continuity Test | Setting Test Conditions
Current rise time
Set the time from when the START switch is pressed until the Test current (p.91) is reached.
1
On the Home menu screen, press Time > Rise Time.
2
Use the numeric keypad or the rotary knob to enter the time.
Setting range: 0.1 s to 200.0 s
This completes the setting.
Current fall time
Set the time for the current to fall from the test current when a PASS judgment is made.
1
On the Home menu screen, press Time > Fall Time.
2
Press Fall Time to switch between on and off.
Fall Time switches between on and off each time you press the key.
3
If you select on, use the numeric keypad or the rotary knob to enter the time.
Setting range: 0.1 s to 200.0 s
This completes the setting.
