Specifications | Leakage current test section
Timer function
Other specifications
Item Specifications
Judgment delay
(Judge Delay)
Setting range 1.0 s to 1 000.0 s, OFF
Accuracy ±(100 ppm of setting + 20 ms)
Test time Setting range 1.0 s to 1 000.0 s, OFF
Accuracy ±(100 ppm of setting + 20 ms)
Item Specifications
Voltage conversion Displays the estimated current converted with the preset supply
voltage (Conv Voltage), based on the voltage supplied to the EUT
and the measured current. (This is invalid in meter mode.)
Setting range 80.0 V to 300.0 V, OFF
Resolution 0.1 V
Power supply line polarity selection Set the polarity of the power supply line to supply to the EUT to
positive or negative.
Single fault mode (Condition) selection Set the EUT single fault mode to normal, neutral line disconnection
(Fault Neu), or protective ground wire disconnection (Fault PE).
Ground check In the touch current test between the enclosure and power supply
line, if the EUT enclosure is grounded, Contact-FAIL occurs.
Measurement check Checks the measurement function by shorting across the A and B
terminals. If an error is found, the protection function is activated.
Supply voltage measurement
AC LINE (EUT)
Measurement
range
80.0 V to 250.0 V
Resolution 0.01 V
Accuracy ±(3 % of reading + 1 V)
Supply current measurement
AC LINE (EUT)
Measurement
range
0.1 A to 15.00 A
Resolution 0.001 A
Accuracy ±(5 % of reading + 30 mA)
Power measurement
(active power)
Measurement
range
10 W to 1 500 W
Accuracy ±(5 % of reading + 8 W) (with the supply voltage at 80 V or more, at a
load power factor of 1)
Voltage
measurement
across the A
and B
terminals
Measurement
range
DC 10.00 V to 300.0 V
RMS 10.00 V to 300.0 V
Peak 15.00 V to 430.0 V
Input impedance Approx. 40 MΩ
Accuracy
1
±(3 % of reading + 2 V) (measurement range fixed to AUTO)
SELV detection Set a voltage for detecting SELV. When the value is exceeded, the
DANGER LED lights.
Setting range 10.0 V to 99.9 V, OFF
Resolution 0.1 V
To Next Page
