304 User’s Manual TOS93 Series
Specifications | Leakage current test section
Judgment function
Item Specifications
Behavior based on judgment Judgment starts after the judgment delay (Judge Delay). Buzzer volume
level can be set in the range of 0 (OFF) to 10 for pass and fail separately.
In an auto test, the buzzer is valid only for the judgment that takes place at
the end of the program.
UPPER
FAIL
Judgment method UPPER FAIL results when a current greater than or equal to the upper
limit (Upper) is detected.
Display “Upper-FAIL” is displayed.
Buzzer On
SIGNAL I/O
The Upper-FAIL signal is generated continuously until a STOP signal is
received.
LOWER
FAIL
Judgment method LOWER FAIL results when a current less than or equal to the lower limit
(Lower) is detected.
Display “Lower-FAIL” is displayed.
Buzzer On
SIGNAL I/O
The Lower-FAIL signal is generated continuously until a STOP signal is
received.
PASS Judgment method PASS judgment is made if Upper-FAIL or Lower-FAIL has not occurred
when the test time elapses.
Display “PASS” is displayed.
Buzzer On (fixed to 50 ms)
SIGNAL I/O The PASS signal is generated for the length of time specified by the Pass
Hold setting. If Pass Hold is set to Infinity, the PASS signal is generated
continuously until a STOP signal is received.
Upper
Setting
range
RANGE
1
Network A, B, C, H DC, RMS: 0.1 μA to 60 μA, Peak: 0.1 μA to 85 μA
Network D, E, I DC, RMS: 0.1 μA to 30 μA, Peak: 0.1 μA to 42.4 μA
Network F DC, RMS: 0.1 μA to 20 μA, Peak: 0.1 μA to 28.2 μA
Network G DC, RMS: 0.1 μA to 15 μA, Peak: 0.1 μA to 21.2 μA
Network PCC-1, PCC-2 DC, RMS: 0.1 μA to 200 μA, Peak: 0.1 μA to 282 μA
RANGE
2
Network A, B, C, H DC, RMS: 61 μA to 600 μA, Peak: 86 μA to 850 μA
Network D, E, I DC, RMS: 31 μA to 300 μA, Peak: 42.5 μA to 424 μA
Network F DC, RMS: 20.1 μA to 200 μA, Peak: 28.3 μA to 282 μA
Network G DC, RMS: 15.1 μA to 150 μA, Peak: 21.3 μA to 212 μA
Network PCC-1, PCC-2 DC, RMS: 201 μA to 2.00 mA, Peak: 283 μA to 2.83 mA
RANGE
3
Network A, B, C, H DC, RMS: 601 μA to 6.00 mA, Peak: 851 μA to 8.50 mA
Network D, E, I DC, RMS: 301 μA to 3.00 mA, Peak: 425 μA to 4.50 mA
Network F DC, RMS: 201 μA to 2.00 mA, Peak: 283 μA to 3.00 mA
Network G DC, RMS: 151 μA to 1.50 mA, Peak: 213 μA to 2.12 mA
Network PCC-1, PCC-2 DC, RMS: 2.01 mA to 20.00 mA, Peak: 2.84 mA to 28.3 mA
RANGE
4
Network A, B, C, H DC, RMS: 6.01 mA to 60.0 mA, Peak: 4.21 mA to 85.0 mA
Network D, E, I DC, RMS: 3.01 mA to 30.0 mA, Peak: 8.51 mA to 45.0 mA
Network F DC, RMS: 2.01 mA to 20.0 mA, Peak: 3.01 mA to 30.0 mA
Network G DC, RMS: 1.51 mA to 15.0 mA, Peak: 2.13 mA to 22.5 mA
Network PCC-1, PCC-2 DC, RMS: 20.1 mA to 100 mA, Peak: 28.4 mA to 100 mA
Lower Setting range A value that is -1 digit from the upper setting range.
Judgment accuracy Conforms to total accuracy (p.303).
(Read “reading” as “setting” of total accuracy.)
