TOS93 Series User’s Manual 301
Specifications | Leakage current test section
Measurement section
Item Specifications
Measurement
range
1
,
resolution
Range1 Network A, B, C, H
DC, RMS: 1.00 μA to 60.00 μA, Peak: 1.00 μA to 85.00 μA
Network D, E, I
DC, RMS: 1.00 μA to 30.00 μA, Peak: 1.00 μA to 42.40 μA
Network F
DC, RMS: 1.00 μA to 20.00 μA, Peak: 1.00 μA to 28.20 μA
Network G
DC, RMS: 1.00 μA to 15.00 μA, Peak: 1.00 μA to 21.20 μA
Network PCC-1, PCC-2
DC, RMS: 1.00 μA to 200.00 μA, Peak: 1.00 μA to 282.00 μA
Range2 Network A, B, C, H
DC, RMS: 50.0 μA to 600.0 μA, Peak: 70.0 μA to 850.0 μA
Network D, E, I
DC, RMS: 25.00 μA to 300.00 μA, Peak: 35.00 μA to 424.00 μA
Network F
DC, RMS: 16.60 μA to 200.00 μA, Peak: 23.30 μA to 282.00 μA
Network G
DC, RMS: 12.50 μA to 150.00 μA, Peak: 17.50 μA to 212.00 μA
Network PCC-1, PCC-2
DC, RMS: 166.0 μA to 2000.0 μA, Peak: 233.0 μA to 2830.0 μA
Range3 Network A, B, C, H
DC, RMS: 0.500 mA to 6.000 mA, Peak: 0.700 mA to 8.500 mA
Network D, E, I
DC, RMS: 250.0 μA to 3000.0 μA, Peak: 350.0 μA to 4500.0 μA
Network F
DC, RMS: 166.0 μA to 2000.0 μA, Peak: 233.0 μA to 3000.0 μA
Network G
DC, RMS: 125.0 μA to 1500.0 μA, Peak: 175.0 μA to 2250.0 μA
Network PCC-1, PCC-2
DC, RMS: 1.660 mA to 20.000 mA, Peak: 2.330 mA to 28.300 mA
Range4 Network A, B, C, H
DC, RMS: 5.00 mA to 60.00 mA, Peak: 7.00 mA to 85.00 mA
Network D, E, I
DC, RMS: 2.500 mA to 30.000 mA, Peak: 3.500 mA to 45.000 mA
Network F
DC, RMS: 1.660 mA to 20.000 mA, Peak: 2.330 mA to 30.000 mA
Network G
DC, RMS: 1.250 mA to 15.000 mA, Peak: 1.750 mA to 22.500 mA
Network PCC-1, PCC-2
DC, RMS: 16.60 mA to 100.00 mA, Peak: 23.30 mA to 100.00 mA
Range switching Auto or Fix selectable. If a measurement falls outside the
measurement range of each range, an error is displayed as a
warning in the measurement value display area.
Auto The range is set automatically according to the
measurements.
Fix For TC, PCC and Patient measurements, the measurement
range is selected automatically according to the UPPER value.
For meter measurements, the range is fixed to the specified
range.
Bandwidth switching Can be expanded to a bandwidth that allows measurements
from 0.1 Hz, which is required in the measurement of medical
instruments and the like.
Normal
Normal measurement bandwidth: 15 Hz to 1 MHz
Expand
Expands the measurement range to 0.1 Hz to 1 MHz
