TOS93 Series User’s Manual 285
Specifications
Unless specified otherwise, the specifications are for the following settings and conditions.
• The product is warmed up for at least 30 minutes.
The used terminology is as follows:
• TY
P: These are typical values that are representative of situations where the product operates in an
env
ironment with an ambient temperature of 23 °C. These values do not guarantee the performance
of this product.
• setting: Indicates a setting.
• range: Indicates the rated value of each range.
• reading: Indicates a readout value.
• The various tests are abbreviated as follows:
ACW: A
C withstanding voltage, DCW: DC withstanding voltage, IR: insulation resistance, EC: earth
con
tinuity, PD: partial discharge, LC: leakage current, TC: touch current, PCC: protective conductor
current, Patient: patient leakage current, Meter: meter mode.
• The following table shows which tests are supported by each model.
Withstanding voltage test section ........................... 286
Insulation resista
nce test section............................ 289
Earth continuity test section
.................................... 294
Partial discharge test section
.................................. 296
Leakage current test section
................................... 299
Interface
.................................................................. 306
Other functions
....................................................... 308
General specifications
............................................ 310
External dimensions
............................................... 311
ACW DCW IR EC PD LC
TOS9300 
–

–
–
–
TOS9301   
–
–
–
TOS9301PD    –  –
TOS9302 
– –
 –
–
TOS9303     –
–
TOS9303LC     – 
