Sensor (pass through) service check
Sensor (envelope feeder empty) service check
Sensor (input) late jam service check.
Step Check Yes No
1 1. Enter the diagnostic mode
2. Select Input tray tests
3. Select Sensor test
4. Select the appropriate tray number
5. Observe the line item “pass through” for the appropriate
media tray
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
The sensor is
working properly
Go to step 2.
2
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
sensor (pass
through).
Go to “250-sheet
controller card
assembly
removal” on
page 4-106.
Replace the
connection.
Step Check Yes No
1 1. Enter the diagnostic mode
2. Select Input tray tests
3. Select Sensor test
4. Select Envelope feeder
5. Observe the line item “empty”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
The sensor is
working properly
Go to step 2.
2
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
envelope feeder.
Replace the
connection.
Use this procedure for the following jams:
• 200.07 • 230.04 • 230.06 • 237.00 • 239.11
• 241.06 • 214.10 • 241.11 • 241.12 • 241.14
• 241.15 • 241.16 • 241.18 • 242.09 • 250.03
• 250.06 • 250.07 • 250.08 • 250.09 • 250.10
• 250.11 • 260.07 • 260.10 • 260.11 • 260.12
• 260.14 • 260.15 • 260.16
