The print registration range is:
5. Continue changing the settings by repeating steps 2 through 4.
6. Print another copy of the Quick Test to verify your changes.
7. To exit REGISTRATION, press Back .
Quick Test
The Quick Test contains the following information:
• Device information
• Current page count, installed memory
• Processor speed
• Serial number
• Engine ID
• System card ID
• Printer revision levels
• Printer margin settings
• Alignment diamonds at the top and bottom
• Horizontal lines to check for skew
To print the Quick Test page:
Note: Print the Quick Test Page on letter or A4 paper.
1. Select REGISTRATION from DIAGNOSTICS.
2. Press until the appears next to Quick Test.
The message Quick Test Printing… appears on the display.
Once the Quick Test Page completes printing, the Registration screen displays again.
Variable Description Value Direction of change
T= Top margin -25 to +25 Each increment causes
approximately 4 pels shift (at 600
dpi).
A positive change moves the image
down the page and increases the
top margin. A negative change
moves the image up and decreases
the top margin.
B= Bottom margin -20 to +20 Each increment causes
approximately 0.55 mm shift in the
bottom margin.
A positive change compresses the
image so it appears to move down
the page and a negative change
moves the image up.
L= Left margin -25 to +25 A positive change moves the image
to the right, and a negative change
moves the image to the left. No
compression occurs.
R= Right margin - 99 to +99 A positive change moves the image
to the right, and a negative change
moves the image to the left.
