5-bin mailbox right inner cover removal
1. Remove the 5-bin mailbox rear door assembly. Go to “5-bin mailbox rear door assembly removal” on
page 4-84.
2. Remove the 5-bin mailbox right outer cover. Go to “5-bin mailbox right outer cover removal” on
page 4-86.
3. Remove the three screws (A) securing the right inner cover to the 5-bin mailbox assembly.
4. Remove the 5-bin mailbox right inner cover.
A
