2-140 Service Manual
4062
Sensor (stapler pass through) late jam service check
Sensor (stapler pass through) lingering jam service check
Step Check Yes No
1 Check the output option for proper installation.
Is the above component properly installed?
Go to step 2. Remove then
reinstall the output
option
2
Check for obstructions in the media path between the base
machine and the output option.
Is the media path free from obstructions?
Go to step 3. Remove
obstructions.
3
Check the sensor (stapler pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Finisher sensor test
3. Select Sensor test
4. Select pass & media
5. Observe the line item “passthru”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 5. Go to step 4.
4
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
stapler unit
assembly.
Go to “SFP
stapler assembly
stapler unit
assembly
removal” on
page 4-183.
Replace the
connection.
5
Perform a print test using the output option.
Does the error continue?
Replace the output
option.
Problem solved.
Step Check Yes No
1 Check the output option for proper installation.
Is the above component properly installed?
Go to step 2. Remove then
reinstall the output
option
2
Check for obstructions in the media path between the
Sensor (stapler pass through) machine and the media bin.
Is the media path free from obstructions?
Go to step 3. Remove
obstructions.
3
Check the sensor (stapler pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Finisher sensor test
3. Select Sensor test
4. Select pass & media
5. Observe the line item “passthru”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 5. Go to step 4.
