Lexmark T650 Series - Paper Jams (Optional External Duplex Unit)

3-100 Service Manual
4062-XXX
Go Back
Previous
Next
231-239 paper jams (optional external duplex unit)
Rear paper jams
1. Push in and hold the latch while pulling up the rear duplex door.
2. Remove the jammed paper.
3. Close the rear duplex door.
4. Press .
Front paper jams
1. Remove the standard tray from the printer.
2. Remove the duplex jam access tray.
1
2
