Use these tests to verify that media can be fed to a specific output bin. Media is fed from the default input
source to the selected output bin. No information is printed on the media fed to the output bin because the
printhead is not engaged during this test. These tests can use any media size or envelope supported by the
printer.
Note: If the Configure Bins printer setting is Link rather than Mailbox, the printer selects its own internal bin
linking regardless of which output bin is selected for the feed test.
To run the Feed Tests for the output bins:
1. Select Feed Tests from the OUTPUT BIN TESTS.
2. Select the output bin you want the paper to exit into. The standard bin as well as any output option bin
installed on the printer is shown on the menu. (The output bins are displayed in the order installed on the
printer.)
3. Select either Single or Continuous.
• Single—feeds one sheet of media from the selected source.
• Continuous—media continues feeding from the selected source until Stop is pressed.
Press Back to return to OUTPUT BIN TESTS.
Feed To All Bins
This test can be used to verify that the printer can feed media to the standard bin or any installed output
options. No information will be printed on the test pages, as the printhead is not engaged during the feed test.
The media feeds from the default paper source.
To run the Feed To All Bins Test:
Select Feed To All Bins from OUTPUT BIN TESTS.
The printer feeds a separate piece of media to the standard bin first, then it feeds a separate piece of media to
each output bin installed in the following order:
The test is continuous until Stop is pressed.
Press Back to return to OUTPUT BIN TESTS.
Sensor Test (standard output bin)
This test is used to verify if the standard bin sensor is working correctly.
Order sheets
are fed
Output bins
Order sheets
are fed
Output bins
Order sheets
are fed
Output bins
1 Standard bin 9 Bin #8 17 Bin #5
2 Bin #1 10 Bin #9, 18 Bin #4
3 Bin #2 11 Bin #10 19 Bin #3
4 Bin #3 12 Bin #10 20 Bin #2
5 Bin #4 13 Bin #9 21 Bin #1
6B
in #5 14 Bin #8 22 Standard bin
7 Bin #6 15 Bin #7
8 Bin #7 16 Bin #6

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
