Diagnostic aids 3-17
4062-XXX
To run the Sensor Test for the standard bin:
1. Select Sensor Test from OUTPUT BIN TESTS.
2. Select Standard Bin from Sensor Tests.
3. Standard Bin Testing displays briefly, and then Bin Empty empty displays.
4. Select NearFull or Full sensor to test.
The following screen is displayed:
Standard Bin x
Full=Open NearFull=Open
Bin Empty empty
• Full—Bin full sensor
• NearFull—Bin near full sensor
5. Manually actuate the bin sensor by moving the flag in and out of the sensor. The display indicates Open
when the flag is out of the sensor and Closed when the flag is in the sensor.
6. Press Back or Stop to exit the test.
Sensor Test (Output Expander)
This test is used to determine whether or not the output bin sensor is working correctly for the output expander,
if installed.
1. Select Sensor Test from OUTPUT BIN TESTS.
2. Select Output Bin x (x=number of the output option to be tested) from Sensor Tests.
The following screen is displayed:
Output Bin x
passThru=Open Full=Open NearFull=Open
• passThru—Pass thru sensor
• Full—Bin full sensor
• NearFull—Bin near full sensor
3. Manually actuate each of the output expander sensors, and the display by each sensor toggles from Open
to Closed.
4. Press Back or Stop to exit the test.
Sensor Test (high capacity output stacker)
1. Select Sensor Test from OUTPUT BIN TESTS.
2. Select Output Bin x (x=number of the output option to be tested).
The following screen is displayed:
HC Bin x TP=OPpassThru=Open Full=Open NearFull=Open
• TP—High-capacity top position sensor
• passThru—High-capacity pass thru sensor
• Full—High-capacity bin full sensor (lower part of dual sensor)
• NearFull—High-capacity bin near full sensor (upper part of dual sensor)
3. Manually actuate each of the sensors of the high-capacity stacker, and the display by each sensor toggles
from Open to Closed.
4. Press Back or Stop to exit the test.
