To run the Sensor Test for the standard bin:
1. Touch to select Sensor Test from OUTPUT BIN TESTS.
2. Touch to select Standard Bin from Sensor Tests.
3. Manually actuate the bin sensor by moving the flag in and out of the sensor, and the display changes.
The following screen is displayed:
Bin Empty: empty or Bin Empty: full.
4. Press Stop to exit the test.
BASE SENSOR TEST
This test is used to determine if the sensors located inside the printer are working correctly.
To run the Base Sensor Test:
1. Select BASE SENSOR TEST from the DIAGNOSTICS menu.
The following sensors are listed:
• Toner Level—Toner level sensor (remove the cartridge and replace to actuate the sensor)
• Input—Input sensor
• Output—Output (exit) sensor
• NarrowMedia—Output (exit) sensor
• Front Door—Front door sensor
2. Manually actuate the sensors to verify that each sensor switches from Open to Closed.
3. Press Stop to exit the test.

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
