3-10 Service Manual
4062-XXX
RFID Option Test
This test confirms that the RFID firmware and hardware are working properly. In the event that the test fails, it
is recommended that the test be repeated to confirm that the problem is not intermittent or caused by a single
failed piece of RFID media.
Note: If the printer has problems picking RFID media from a tray, try using a shorter stack of media (< 100
sheets) before assuming a pick mechanism problem.
To run the RFID Option Test, select RFID Option Test from the menu.
1. Load RFID media in Tray 2, and then press Continue. The test page will be printed.
Note: For this test to work properly, the RFID media used for the test should contain an RFID tag that is
positioned within the first-half of the page from the leading edge.
If the page looks like this: If the page looks like this:
Then step 1 of the test passed.
Proceed to step 2
Then the test has failed.
This is an indication that the RFID
tag could not be written to.
Possible causes:
1. Bad RFID media
2. RFID UHF option failure
Try the test again with a new piece
of RFID media. If the test fails
again, replace the RFID UHF
option.
T65x RFID Option Test
Step 1.
Step 1 is complete.
1. Place this sheet in Tray 2 face-down with the
arrow pointing toward the front of the printer.
2. Press Continue.
T65x RFID Option Test
Step 1.
Step 1 is complete.
1. Place this sheet in Tray 2 face-down with the
arrow pointing toward the front of the printer.
2. Press Continue.
