Lexmark T650 Series Service Manual

4-104 Service Manual
4062-XXX
Go Back
Previous
Next
250-sheet media out actuator removal
Note: Carefully remove the base machine from the input option tray assembly before proceeding.
1. Remove the 250-sheet pick arm bracket assembly. Go to “250-sheet pick arm bracket assembly
removal” on page 4-102.
2. Release the hook (A) securing the 250-sheet media out actuator to the 250-sheet pick arm bracket
assembly.
3. Remove the 250-sheet media out actuator from the drawer.
250-sheet frame assembly removal
Note: The 250-sheet frame assembly is not a FRU.
1. Remove the 250-sheet pick arm bracket assembly. Go to “250-sheet pick arm bracket assembly
removal” on page 4-102
2. Release the hooks securing the sensor (pass through) to the drawer.
3. Remove the sensor (pass through) from the drawer.
A

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
