Parts catalog 7-1
4062-XXX
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and the item number 1.
• Part number: identifies the unique number that identifies this FRU.
• Units/mach: refers to the number of units actually used in the base machine or product.
• Units/option: refers to the number of units used in the option and does not include the base machine.
• Units/kit or Pkg: refers to the number of units packaged together and identified by the part number.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• PP: (Parts Packet) in the parts description column indicates the part is contained in a parts packet.
Model information used in the parts catalog.
Asm-
Index
Part
number
Units/mach
- OR -
Units/option
Units/
kit or
pkg
Description
Machine type Model Configuration
4062-01A T650n Network
4062-21A T652n Network
4062-23A T652dn Network
4062-41A T654n Network
4062-43A T654dn Network
4062-630 T656dne Network
4062-41G TG654n Newwork
