3-12 Service Manual
4062-XXX
3. Load plain media in Tray 2, and then press Continue. The test page will be printed.
DUPLEX TESTS
Quick Test (duplex)
This test prints a duplex version of the Quick Test that can be used to verify that the correct placement of the
top margin on the back side of a duplex page. You can run one duplexed page (Single), or continue printing
If the page looks like this: If the page looks like this:
Then step 3 of the test passed and
the RFID Option Test is complete.
The RFID firmware and hardware
are working properly.
Then the test has failed.
This is an indication that the printer
was able to read an RFID tag when
it was not supposed to.
Possible causes:
1. RFID media was printed
instead of plain media.
2. A separate RFID tag may be
placed in close proximity to the
RFID option.
3. RFID UHF option failure
Try the test again, making sure that
plain media is used for step 3. If the
test fails again, inspect the printer
to make sure there are no RFID
tags in close proximity to the RFID
option. For example, it an RFID tag
was applied to the printer front
cover itself, this tag may be
causing problems with the RFID
reader. If no problems found,
replace the RFID UHF option.
T65x RFID Option Test
Step 3.
If this image
Step three is complete.
appears at the bottom of this sheet, the
test is a SUCCESS.
T65x RFID Option Test
Step 3.
If this image
Step three is complete.
appears at the bottom of this sheet, the
test is a SUCCESS
