Diagnostic aids 3-25
4062-XXX
Configuration menu (CONFIG MENU) (models T650, T652, and T654)
Entering Configuration Menu (models T650, T652, and T654)
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons after ten seconds.
The message CONFIG MENU displays on the top line of the operator panel.
Available menus
Some menus are not available, depending on the configuration of the printer.
Maintenance page count (Maint Cnt Value)
The current value for the maintenance page counter is displayed. This counter tracks printer usage. A print job
containing a single page increments the counter by one and a duplex page by two. At 300,000, the customer is
reminded that the printer requires scheduled maintenance. This counter is reset by the servicer after an 80
Scheduled Maintenance message displays, and a maintenance kit is installed. See “Maintenance kit” on
page 6-2 for the part number.
Maint Cnt Value See “Maintenance page count (Maint Cnt Value)” on page 3-25
Reset Cnt See “Maintenance page counter reset (Reset Cnt)” on
page 3-26
Prt Quality Pgs See “Print quality pages (Prt Quality Pgs)” on page 3-26
Reports See “Reports” on page 3-26.
SIZE SENSING See “SIZE SENSING” on page 3-27
Panel Menus See “Panel Menus” on page 3-27
PPDS Emulation See “PPDS Emulation” on page 3-27
Demo Mode See “Demo Mode” on page 3-27
Factory Defaults See “Factory Defaults” on page 3-28
LES Applications See “LES Applications” on page 3-28
Energy Conserve See “Energy Conserve” on page 3-28
Paper Prompts See “Paper Prompts” on page 3-28
Env Prompts See “Env Prompts” on page 3-28
Action for Prompts See “Action for Prompts” on page 3-28
Font Sharpening See “Font Sharpening” on page 3-28
Wiper Messages See “Wiper Messages” on page 3-28
Clear Custom Status See “Clear Custom Status” on page 3-28
Best Speed See “Best Speed” on page 3-29
Exit Config Menu
