High capacity input tray (HCIT) media tray assembly removal
1. Open the HCIT media tray assembly until it reaches a stop.
2. Press the latches (A) on the left and right sides of the HCIT tray slides.
3. Slide the HCIT media tray assembly out of the drawer.
A
A
