Lexmark T650 Series Service Manual

Diagnostic aids 3-97
4062-XXX
Go Back
Previous
Next
WARNING: Do not leave the cartridge exposed to light for extended periods.
WARNING: The jammed paper may be covered with unfused toner which can stain garments and skin.
5. Remove the jammed paper.
CAUTION: The inside of the printer might be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching.
Note: If the paper is not easy to remove, then open the rear door and remove the paper from there.
6. Align and reinstall the print cartridge.
7. Close the front cover.
8. Close the multipurpose feeder door.
9. Press .
202 and 203 paper jams
If the paper is exiting the printer, then pull the paper out, and then press .
If the paper is not exiting the printer:
1. Pull down the top rear door.
2. Slowly remove the jammed paper to avoid tearing it.
3. Close the top rear door.
4. Press .

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
